SINGLETWIST® Knot, 0.014 Inch
$0.00
Product information "SINGLETWIST® Knot, 0.014 Inch"
Technical information
0.014 Inch
| Brush Diameter | 1/4 Inch |
| Filament Material | Steel wire (ST) |
| Wire Diameter | 0.014 Inch |
| Shank Diameter | 1/4 Inch |
| Trim Length | 1 1/8 Inch |
| Number of Knots | 1 |
| Max. RPM | 20000 RPM |
| Pack Qty | 10 |
Innovative and flexible single-knot brush for special applications. Steel wire is the most common filament material. Brushes with steel wire as the filament material are ideal for work on surfaces and deburring. PFERD special wire has high tensile strength and bending fatigue strength. This ensures that the wire wears down in the optimal way, as well as a long tool life, even in extreme brushing applications. Steel wire is temperature-resistant up to 600°F.
Advantages
- Optimal access to hard-to-reach areas such as inside corners, as the knot is less likely to unravel.
- Long service life through use of PFERD special wire.
Applications
- Cleaning
- Deburring
- Derusting
- Descaling
- Removing oxide layers
- Paint stripping
- Root seam processing
- Work on weld seams
- Work on fillet welds
Materials that can be worked
- Steel, cast steel
- Steel materials with a hardness > 54 HRC
- Steels up to 370 HV (< 38 HRC)
- Cast iron
- Cast steel
Drive Types
- Flexible shaft drive
- Power drill
- Straight grinder
Safety
When clamping the brush, ensure that the shank is clamped as far into the arbor as possible. This especially applies to high rotational speed ranges. The minimum clamping length is 10 mm.
| Brush Diameter: | 1/4 Inch |
|---|---|
| Drive Type: | Flexible shaft drive, Power drill, Straight grinder |
| Filament Material: | Steel wire (ST) |
| Max. RPM: | 20000 RPM |
| Pack Qty: | 10 |
| Trim Length: | 1 1/8 Inch |
