COMBICLICK® Fiber Disc, 4 1/2" Dia, 60 Grit, 64194006
$0.00
Product information "COMBICLICK® Fiber Disc, 4 1/2" Dia, 60 Grit, 64194006"
Technical information
4 1/2" Dia, 60 Grit
| Dia. External | 4 1/2 in |
| Drive type | Angle grinder |
| Grit | 60 |
| Max. RPM | 13300 |
| Pack qty | 25 |
The COMBICLICK® system consists of a specially developed backing pad and a rugged mounting system at the back of the disc. The backing pad allows COMBICLICK® discs to be used on most available angle grinders. The special geometry of the cooling slots ensures high air throughput, which considerably reduces the thermal load on the abrasive material and the workpiece. The quick-mounting system, rugged fixture, secure attachment of the disc and optimized cooling system help to provide up to 30% lower workpiece temperature, up to 25% increased stock removal, up to 30% longer disc life and improved utilization of the abrasive. PFERD fiber discs are manufactured in accordance with ISO 16057 in shape A1 version F under the designation "vulcanized fiber disc". For aggressive grinding with maximum stock removal on non-ferrous metals. Consistently high performance due to self-sharpening ceramic oxide grain. Adhesion-reducing additives in the coating prevent loading.
Special features
- Innovative quick-mounting system guarantees convenient handling and cool grinding
- High productivity due to long service life and very high stock removal rate.
- Consistent surface finish resulting from high-quality abrasives.
- Extremely quick and easy disc changes reduce process costs.
- With COMBICLICK®, scratches caused by protruding clamping parts are prevented and very high utilization of the available abrasive is attained.
Applications
- Deburring
- Step-by-step fine grinding
- Leveling
- Surface work
- Work on weld seams
- Working on edges
Materials that can be worked
- Tough aluminium alloys
- Zinc
- Aluminum
- Brass
- Copper
- Hard aluminium alloys
- Other non-ferrous metals
- Soft aluminium alloys
Recommendations for use
- Use COMBICLICK® fiber discs with COMBICLICK® backing pads on commercially available angle grinders.
- Use the appropriate grinding oil for the material to significantly increase the service life and the abrasive performance of the discs.
Safety
- The maximum permitted peripheral speed is 15,800 SFPM.
- For safety reasons, the maximum permitted rotational speed indicated must never be exceeded.
| Pack Qty: | 25 |
|---|
